Available Series
- PQ high-frequency transformers
- EC high-frequency transformers
- EE high-frequency transformers
- Custom high-frequency transformer assemblies
Product Category
High-Frequency Transformers
High-frequency transformer products for SMPS, isolated converters, chargers, industrial power modules and custom magnetic component projects.
Manufactured by MiDEN Electronics. Send drawings, samples or target specifications for quotation support.
Catalog-Verified Technical Information
Technical Specifications and Selection Guidance
Specification scope referenced from MiDEN 2024 Product Catalog, pages 12-13 and 64-66. Electrical values and dimensions are confirmed by series and part number.
Parameters for Selection
- Core and bobbin size
- Turns ratio
- Primary inductance
- Input and output requirement
- Switching frequency
- Insulation and pin layout
Typical Applications
- Switch-mode power supplies
- Isolated converters
- EV charging equipment
- Industrial power modules
- Auxiliary power supplies
Custom Engineering Options
- Core and bobbin selection
- Winding and turns ratio
- Isolation and hipot target
- Pin configuration
- Thermal and mechanical design
Specification Note
The catalog lists PQ, EC and EE transformer families with series-specific dimensions and electrical data. Final selection depends on converter topology, waveform, switching frequency, isolation class, temperature and production test requirements.
Send the target application, electrical conditions, drawing or sample photo to receive a series recommendation and confirmed specification.
Request Technical Review / RFQProduct Gallery
High-Frequency Transformers product selection
Review available constructions and contact our team to confirm electrical specifications, dimensions, samples and production requirements.
High-Frequency Transformers
High-Frequency Transformer Series
Transformer solution for SMPS, converters and industrial power modules.
